Carbonated soft drinks look simple in a bottle or can—but filling them at scale is a pressure-and-precision balancing act. If the process is too aggressive, CO₂ breaks out of solution, foam erupts, fill levels drift, and product quality becomes inconsistent. If the process is too slow, output drops
Choosing the right production equipment can make or break a beverage brand’s ability to scale. When orders grow, manual steps and semi-automatic processes often become the bottleneck—creating inconsistent fills, wasted product, slower changeovers, and rising labor pressure. That’s why many m
| Availability: | |
|---|---|
| Quantity: | |
By integrating these functions into one machine, it significantly reduces production time and labor costs.
Ensures consistency in filling and capping processes, maintaining product quality and integrity.
Adaptable to different production environments, whether for water, oil, or other liquid products.
Technical Parameter | ||||||
Model | CGF8-8-3 | CGF14-12-5 | CGF16-16-5 | CGF24-24-8 | CGF32-32-8 | CGF40-40-10 |
Capacity | 2000-3000 | 4000-5000 | 6000-8000 | 10000-12000 | 13000-15000 | 18000-20000 |
Bottle shapes | Round, Square or Other | |||||
Bottle diameter | 50-115mm | |||||
Bottle height | 160-320mm | |||||
Compressor air | 0.3-0.7Mpa | |||||
Washing meidium | Pure Water | |||||
Rinsing pressure | >0.06Mpa <0.2Mpa | |||||
Application | Water Bottling Plant | |||||
Motor power | 1.5kW | 1.5kW | 2.2kW | 3kW | 3kW | 5.5kW |
Overall dimensions | 2.0*1.5m | 2.4*1.8m | 2.7*2.2m | 2.8*2.4m | 3.6*2.7m | 4.4*3.3m |
Height | 2.5m | 2.7m | 2.7m | 2.7m | 2.7m | 2.7m |
Weight | 2500kg | 3500kg | 4500kg | 5500kg | 6500kg | 7500kg |
By integrating these functions into one machine, it significantly reduces production time and labor costs.
Ensures consistency in filling and capping processes, maintaining product quality and integrity.
Adaptable to different production environments, whether for water, oil, or other liquid products.
Technical Parameter | ||||||
Model | CGF8-8-3 | CGF14-12-5 | CGF16-16-5 | CGF24-24-8 | CGF32-32-8 | CGF40-40-10 |
Capacity | 2000-3000 | 4000-5000 | 6000-8000 | 10000-12000 | 13000-15000 | 18000-20000 |
Bottle shapes | Round, Square or Other | |||||
Bottle diameter | 50-115mm | |||||
Bottle height | 160-320mm | |||||
Compressor air | 0.3-0.7Mpa | |||||
Washing meidium | Pure Water | |||||
Rinsing pressure | >0.06Mpa <0.2Mpa | |||||
Application | Water Bottling Plant | |||||
Motor power | 1.5kW | 1.5kW | 2.2kW | 3kW | 3kW | 5.5kW |
Overall dimensions | 2.0*1.5m | 2.4*1.8m | 2.7*2.2m | 2.8*2.4m | 3.6*2.7m | 4.4*3.3m |
Height | 2.5m | 2.7m | 2.7m | 2.7m | 2.7m | 2.7m |
Weight | 2500kg | 3500kg | 4500kg | 5500kg | 6500kg | 7500kg |
